90° Wide-angle Lens
Adopts 90° high-quality ultra-wide focal lens,providing a panoramic view.
AI humanoid tracking
Using the deep learning technology to extract the target's characteristics and allow smooth face tracking, no matter where the face is facing. It is suitable for application scenarios such as presenter automatic tracking and can flexibly select tracking targets.
Specifications
Camera
- Sensor:1/2.9'', CMOS, Max Effective Pixel
- Scanning Mode:Progressive
- Lens :3x, f3.35mm ~ 10.05mm, F1.7 ~ F3.0
- Digital Zoom:16x
- Minimal Illumination:0.5Lux @ (F1.8, AGC ON)
- Shutter:1/30s ~ 1/10000s
- White Balance:Auto, Indoor, Outdoor, One Push, Manual,VAR
- Backlight Compensation :Support
- Digital Noise Reduction:Â 2D&3D Digital Noise Reduction
- S/N :≥55dB
- Horizontal Angle of View:90° ~ 30.7°
- Vertical Angle of View:52° ~ 18.4°
- Horizontal Rotation Range:±170°
- Vertical Rotation Range :-30° ~ +90°
- Pan Speed Range:2.7° ~ 35.7°/s
- Tilt Speed Range:2.7° ~ 31.5°/s
- H & V Flip:Support
- Image Freezing:Support
- Number of Preset:255
- Preset Accuracy:0.1°
Input/output Interface
- USB Interface:1xUSB 2.0, Type-C
- Audio Input:Built-in dual Mics
- Communication Interface:1xRS232 In
- Power Jack:JEITA (DC IN 12V) /USB Type-C (DC IN 5V)
USB Features
- Operating System:Windows 7, Windows 8, Windows 10,Windows 11, Mac OS X, Linux, Android
- Color System / Compression:YUY2 / MJPEG
- Video Format:YUY2 (Isochronous mode) Max 640x480P30ï¼›MJPEG Max 1920x1080P30
- Audio on USB:Support
- USB Video Communication Protocol:UVC 1.1
- UVC PTZ Control:Support
Generic Specifications
- Input Voltage:Â DC 12V/ USB 5V
- Input Current:Â 12V 1.0A(Max)/5V 1A(Max)
- Operating Temperature: -10°C ~ 40°C
- Storage Temperature:-40°C ~ 60°C
- Power Consumption:12W（Max）
- MTBF:>30000H
- Size:Â 144mm x 144mm x 167.9mm
- Net Weight:0.444kg
