RC821U supports 12x optical zoom and 16X digital zoom to catch every details in around 12 meters. The horizontal rotation range of the PTZ is close to 360° while the vertical tilt range is from -30° - +90°.

1080P FULL HD
Adopt Panasonic's 1/2.8 inch, 2.07 million effective pixels high quality HD CMOS sensor, which can reach maximum 1920 x 1080 high resolution, output frame rate up to 60fps and display clear video,vividly represent the expressions and movements of the characters.

The exclusively customized 72.5° high-quality ultra-wide-angle lens, support 12x optical zoom and 16x digital zoom.


RC821U can accurately obtain the number and distribution of participants through face detection, intelligently control PTZ cameras to capture all participants in the screen, and adjust to the best screen.
Multiple video interfaces, support HDMI, USB3.0 and AV output.
And has 3 ways of power supply.
Simultaneously support to use 5V USB cable, 12V power cable and PoE for power supply.


The wired network supports PoE power supply, the control, power supply, video and audio can be completed with a network cable.
Remote Control
The camera can be controlled remotely through the RS232, network and USB port.



Specifications
Camera
- Video System :1080P60, 1080P50, 1080P30, 1080P25, 720P60,720P50
- Sensor : 1/2.8'', CMOS, Effective Pixel: 2.07M
- Scanning Mode : Progressive
- Minimal Illumination : 0.5Lux @ (F1.8, AGC ON)
- Lens :12x, f3.5mm ~ 42.3mm, F1.8 ~ F2.8
- Shutter : 1/30s ~ 1/10000s
- White Balance : Auto, 3000K/Indoor, 4000K,5000K/Outdoor, 6500K_1, 6500K_2, 6500K_3, One Push, Manual
- Backlight Compensation : Support
- Digital Noise Reduction : 2D&3D Digital Noise Reduction
- Video S/N : ≥55dB
- Horizontal Angle of View : 72.5° ~ 6.9°
- Vertical Angle of View : 44.8° ~ 3.9°
- Horizontal Rotation Range : ±170°
- Vertical Rotation Range : -30° ~ +90°
- Pan Speed Range : 2.7° ~ 35.7°/s
- Tilt Speed Range : 2.7° ~ 31.5°/s
- H & V Flip : Support
- Image Freeze : Support
- Number of Preset : 255
- Preset Accuracy : 0.1°
Input/Output Interface
- USB Interface : 1xUSB 3.0 , Type-C Jack
- HDMI Output interface : 1xHDMI1.4b
- Network Interface : 1xRJ45: 10M/100M Adaptive Ethernet
- Audio Interface : 1x Line In, 3.5mm Audio Interface, Line In
- Power Jack : JEITA type (DC IN 12V)/USB C type(DC IN 5V)
- Communication Interface : 1xRS232 In: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P
USB Features
- Operate System : Windows 7, Windows 8, Windows 10, Mac OS X, Linux, Android
- Color System /Compression : YUY2 / MJPEG / H.264
- Audio on USB : Support
- Video Format : YUY2 : Max1080P@60fps MJPEG: Max1080P@60fps H.264 : Max1080P@60fps
- USB Video Communication Protocol : UVC 1.1
- UVC PTZ Control : Support
IPC Features
- Video Compression : H.264/MJEPG
- Video Stream : Main Stream, Sub Stream
- Main Stream Resolution : 1920x1080,1280x720,1024x576,960x540,640x480,640x360
- Sub Stream Resolution : 1280x720,1024x576,
720x576(50Hz Support),
720x480(60HZ Support),720x408,
640x360,480x270,320x240,320x180 - Video Bit Rate : 32Kbps ~20480Kbps
- Bit Rate Type : Variable Rate, Fixed Rate
- Frame Rate : 50Hz: 1fps ~ 50fps,
60Hz: 1fps ~ 60fps - Audio Compression : AAC
- Audio Bit Rate : 96Kbps, 128Kbps, 256Kbps
- Support protocols : TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, etc.
General specification
- Input Voltage : DC 12V/DC 5V/PoE(802.3af)
- Input Current : 12V 1.0A(Max)/5V 1A(Max)
- Operating Temperature : -10°C ~ 40°C
- Power Consumption :12W (Max)
- Storage Temperature : -40°C ~ 60°C
- Size : 142*152*176mm
- Net Weight : 1.5kg
- MTBF : >30000H
